Specifications | GMS-B100B | GMS-B100W |
LED modules | 4 LED modules | 4 LED modules |
Solar panel | 18V 120W Monocristalino | 32V 130W Monocristalino |
Battery | Grade A LiFePO4 Lithium Real 12.8V 45AH/576WH | Grade A LiFePO4 Lithium Real 12.8V 60Ah 768WH |
LED lamp power | 12V 200W | 12V 200W |
System power | 100W | 100W |
Controller | IP68 MPPT-Max Power Point Tracking/Intelligent Power Management/Microwave Radar Sensor (PIR or 10 sections timer as optional) | |
LED chips | SMD3030/5050/LED Lumen: 210Lm/W | |
Lighting lumens | 14000-15000Lm | 16000-17000Lm |
LED lifespan | 100,000 hours | 100,000 hours |
Color temperature | 3000K 4000K 6000K | 3000K 4000K 6000K |
Color Rendering Index | Ra80 | Ra80 |
Lighting beam angle | 140*70° | 140*70° |
Solar charging time | 5-6 hours | 5-6 hours |
Discharging time | Bright Mode: 14 hours Dim mode:3-5 raining days | Bright Mode: 14 hours Dim mode:3-5 raining days |
Pole height | 8m 9m 10m | 8m 9m 10m 12m |
Pole distance | 30-35m | 30-35m |
Lamp Material | Aluminum | Aluminum |
Lamp size | 1400*430*50mm | 1570*430*50mm |
Bracket | Arm tube/Top post/Adjustable arm/Customize | |
Application | Street road/village road/garden/park/parking lot/courtyard | |
